Products Description
Application:
It is suitable for the scale production of sawmill and is widely used in wood processing in the original forest area.
Features:
1.Hand forward and backward,hand lifting.
2.Power is gasoline engine/electric motor
3.It is also effective for hardwood
Product parameters
| Sawmill parameters | DB59 | DB69 | DB80 | DB1000 | ||
| Max Log Cutting Dia(cm) | 60 | 70 | 92 | 105 | ||
| Max Log Cutting Dia(inch) | 24 | 28 | 36 | 41 | ||
| Max Log Cutting Length | 3.5m | 3.5m | 3.5m | 3.5m | ||
| Track Length | 4m | 4m | 4m | 4m | ||
| Motor Power | 5.5KW/18HP | 5.5KW/18HP | 7.5KW/18HP | 11KW/27HP | ||
| Engine power | Electricity/Gasoline/Diesel | Electricity/Gasoline/Diesel | Electricity/Gasoline/Diesel | Electricity/Gasoline/Diesel | ||
| Packing Size | 2.1m*1m*1.5m | 2.1m*1m*1.6m | 2.1m*1m*1.76m | 2.1m*1m*1.76m | ||
| Voltage Options | 220V/380V | 220V/380V | 220V/380V | 380V | ||
| Saw Wheel Diameter | 400mm | 400mm | 500mm | 500mm | ||
| Blade Size | 3300*35*0.9mm | 3500*35*0.9mm | 4200*35*0.9mm | 4200*35*0.9mm | ||
| Lifting | manual | manual | manual | manual | ||
| Walking | manual | manual | manual | manual | ||
| Safe cutting Speed | 6m/min | 6m/min | 4m/min | 4m/min | ||
| Dimension | 4m*2.5m*1.8m | 4m*2.5m*1.8m | 4m*2.5m*1.8m | 4m*2.5m*1.8m | ||
| Weight | 500kg | 550kg | 650kg | 770kg | ||
| Warranty | 1 year | 1 year | 1 year | 1 year | ||
| Color customization | Supported | Supported | Supported | Supported | ||
| Logo customization | Supported | Supported | Supported | Supported | ||
Packaging&Shipping
Company Photos
