Farm Dumper Truck Parameter
Model | Square head (single cylinder) DB-253 | Square/round head (double cylinder) DB-385 | Square/round head (four cylinders) DB-586 | Square/round head (four-cylinder pressurized) DB-786 | Square/round head (four-cylinder pressurized) DB-1026 |
colour | Five colors: red, blue, army green, yellow, green | ||||
Engine type | Diesel engine: single cylinder 25/28/32 hp | Diesel engine: double cylinder 38hp | Diesel engine: four-cylinder 58 hp | Diesel engine: four-cylinder supercharged 78 hp | Diesel engine: four-cylinder 4102 supercharged 102 hp |
Gearbox model | 10 Gearbox with high and low speed | 130 Gearbox with high and low speed | 130 Gearbox with high and low speed | 140 Gearbox with high and low speed | 145 Gearbox with high and low speed |
Gear | 7/10 speed | 10/12 speed | 10/12 speed | 10/12 speed | 10/12 speed |
Drive method | All-wheel drive | All-wheel drive/Time-sharing four-wheel drive | |||
Load | 3T | 3-5T | 6-12T | 6-12T | 6-12T |
Tyre model | 700-16/750-16/825-16 customizable | 700-16/750-16/825-16 customizable | 700-16/750-16/825-16 customizable | 700-16/750-16/825-16 customizable | 700-16/750-16/825-16 customizable |
Number of tires | 4 rounds | 6 rounds | 6 rounds | 6 rounds | 6 rounds |
Front/rear axle | 212/130 | 130/ISUZU | 130/ISUZU | ISUZU/ISUZU | ISUZU/1061 & ISUZU/1080 |
Steering method | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering |
Unloading method | Double-cylinder hydraulic semi-automatic unloading | ||||
Battery specifications | Double battery 24V (60 mA) | Double battery 24V (60 mA) | Double battery 24V (60 mA) | Double battery 24V (60 mA) | Double battery 24V (60 mA) |
Brake | Oil brake | Oil brake | Oil brake | Oil brake | Oil brake |
Truck body type | Agricultural carriage (small model)/(large model)/Grain loading wagon/Flatbed trailer | ||||
Cargo box size | 2200*1800*450 | 2200*1700*450 | 2200*1800*500 | 2200*1800*500 | 2200*1800*500 |
Overall dimension (LxWxH)(mm) | 3900*1800*2300 | 3900*1700*2300 | 3900*1800*2300 | 3900*1800*2300 | 3900*1800*2300 |
Farm Dumper Truck Details
Many Types You Can Choose
Our Factory
Farm Dumper Truck Application
