Description of logging truck with crane:
The logging truck with crane is an incredibly useful and efficient tool for the logging industry. It is a heavy-duty truck equipped with a powerful crane that allows for quick and easy loading and unloading of logs.
The crane is typically mounted on the back of the truck and can be used to lift logs onto the bed of the truck, or to move them from the ground to a trailer. This saves a tremendous amount of time and effort compared to manually loading logs onto a truck bed.
| Part I Log Timer Crane | ||||||
| Log Timber crane | Model | TC650 | TC650L | TC650Z | TC700 | TC780 |
| Arm length(m) | 6.5 | 6.5 | 6.5 | 7 | 7.8 | |
| Rotary torque (KN.M) | 11 | 18 | 19 | 19 | 19 | |
| Rotation angle | 380° | 380° | 380° | 380° | 380° | |
| Number of rotating cylinders(piece) | 4 | 4 | 4 | 4 | 4 | |
| Lifting force at 4 m(kg) | 750 | 2000 | 1950 | 1900 | 1880 | |
| Lifting force at full length (kg) | 500 | 1100 | 1000 | 830 | 720 | |
| Grab swing brake from side to side | yes | yes | yes | yes | yes | |
| Grab swing brake back and forth | yes | yes | yes | yes | yes | |
| Telescopic boom structure | yes (Telescopic stroke 1.2meter) | yes (Telescopic stroke 1.2meter) | yes (Two-section telescopic boom at the same time telescopic stroke 1.0 meters) | yes (Two-section telescopic boom at the same time telescopic stroke 1.6 meters) | yes (Two-section telescopic boom at the same time telescopic stroke 1.6 meters) | |
| Boom 360° rotary valve | 1pcs | 1pcs | 1pcs | 1pcs | 1pcs | |
| One-way throttle valve for 360° rotation of boom | 2pcs | 2pcs | 2pcs | 2pcs | 2pcs | |
| balance valve | 1pcs | 1pcs | 1pcs | 1pcs | 1pcs | |
| Recommended hydraulic oil flow (L/min) | 40-50 | 45-55 | 45-70 | 45-70 | 45-70 | |
| Working pressure (MPa) | 20 | 20 | 22 | 22 | 22 | |
| Standard rotary motor | GR-30F(3T flange type)) | GR-30F(3T flange type)) | GR-30F(3T flange type)) | GR-30F(3T flange type) | GR-30F(3T flange type) | |
| The standard grab | TG20(Maximum Opining 1260mm) | TG20Z(Maximum Opining 1260mm) | TG20Z(Maximum Opining 1260mm) | TG26(Maximum Opining 1470mm) | TG26(Maximum Opining 1470mm) | |
| Total weight (no leg, valve block) (kgs) | 840 | 1000 | 1090 | 1150 | 1230 | |
| surface coating | Spray plastic (big and small arms, column base, fixture teeth are red, others are black) | |||||
| hydraulic tubing | The oil inlet diameter is 13 and the oil return diameter is 16, which is matched with G1 / 2"quick connector. The forearm of main boom is equipped with external iron tubing | The oil inlet diameter is 16 and the oil return diameter is 19, which is matched with G3 / 4 "quick connector. The forearm of main boom is equipped with external iron tubing | ||||
Company infomation of logging truck with crane:
Our company takes pride in providing top-quality logging trucks with cranes - the perfect solution for logging professionals. Our model is designed to meet the demands of tough environments and tough jobs, while ensuring that you get the best value for your investment.
Our logging trucks with cranes are built to last and provide exceptional performance that meets the needs of various industries. They are tested to ensure that they work efficiently under different conditions and terrains, making them suitable for both novice and experienced operators. Our company uses high-quality materials and advanced technologies to ensure that our logging trucks with cranes meet your exact needs and specifications.
If you are interested in logging truck with crane, please feel free to contact us:
