18 HP Walking Tractor with 151 Chassis
2 wheels walking tractor is a traction and driving dual-use walking tractor. The supporting power is 12-22 hp diesel engine. The user can match other types of diesel engines whose power does not exceed the specified value according to actual needs. The machine has the advantages of simple and compact structure, light and flexible operation, light weight, reliable use, convenient maintenance and good versatility.Reliable lubrication performance, perfect control of dynamic balance. Low fuel consumption, fast speed, strong horsepower. Advanced combustion system, adequate air intake, more complete combustion, more power, super fuel-efficient, super reliable.
| PARTⅠ 18HP WALKING TRACTOR | |||||
| Model | DB18-151 | ||||
| Structure Weight (kg) | 395 (with connecting frame) | ||||
| 518(with rotary tiller) | |||||
| Overall dimensions (L X W X H)(mm) | 2900*960*1280(without seat) | ||||
| Number of blades(Pcs) | 24PCS, 26PCS | ||||
| Rototiller width(mm) | 900 or 1000 | ||||
| Rototiller depth(mm) | 300 | ||||
| Type of tractor | Single axle, dual –purpose for both tractor and drive | ||||
| Traveling Speed(km/h) | Forward | 1.4,2.5,4.1,5.3,9.4,15.3 | |||
| Reverse | 1.1,3.8 | ||||
| Tyre size | 600-12 Off-road rubber wheel(paddy field anti-skid water wheels available) | ||||
| Wheel track(mm) | 800,740,640,580 (normally use 800) | ||||
| Min.ground clearance(mm) | 185 | ||||
| Min.turning radius(m) | 0.9(with no rotavator) | ||||
| Model of engine | ZS1105 diesel | ||||
| Type of engine | Horizontal, Single cylinder, 4-stroke | ||||
| Number of cylinders | single cylinder | ||||
| Cylinder diameter | 100mm | ||||
| Piston stroke | 115mm | ||||
| Total displacement(L) | 0.913 | ||||
| Turing speed of crankshaft | 2200 | ||||
| Rated power | 18HP- 13.23 kw | ||||
| Specific fuel consumption(g/kw.h) | ≤320 | ||||
| Specific lube oil consumption(g/kw/h) | ≤2.72 | ||||
| Cooling model | Water cooling | ||||
| Start model | Manual start | ||||
| Package | Engine by plywood box, chassis by wear foam | ||||
| 20GP Quantity | 30PCS | ||||
| 40HQ Quantity | 80PCS | ||||
Product Application of walking tractor
Package and shipping of 18 HP Walking Tractor with 151 Chassis
