Parameter
Product features of two busy loader:
1. Low fuel consumption, strong power, high reliability.
2. Equipped with closed wet double brakes, large bearing capacity, high reliability, more suitable for all kinds of harsh conditions.
3. Adopt load sensing hydraulic steering system, steering light and fast, smooth operation, stable and reliable performance;Equipped with hydraulic system with combination and split logic function, the compound action of mining operation can be realized.
4. Can be equipped with standard bucket rod or telescopic bucket rod, to meet the diversified needs of customers.
5. The use of floor glass around the cab, a wide field of vision, standard air-conditioning, driving environment is comfortable.
6. Can be configured with a variety of mining or loading fixtures, to meet the diverse needs of users.
Parameter
Model | 945-65 |
Engine Model | YUNNEI 4105 pressure |
Rated Power | 110KW |
Rated Speed | 2400r/min |
Number of cylinders - inner diameter | 4-105 |
Dimension | 7000*2000*2850mm |
Wheel Base | 2720mm |
Minimum ground clearance | 320mm |
The performance parameters | |
System Pressure | 28Mpa |
Weight | 8500kg |
Maximum speed | 38km/h |
Max Climb Capability | 35° |
Minimum turning radius | 4300mm |
Mining parameters | |
Maximum excavation depth | 3000mm |
Excavation unloading height | 4100mm |
Maximum excavation radius | 4800mm |
Bucket width | 60mm |
Bucket capacity | 0.25m³ |
Maximum excavation height | 5600mm |
Maximum Digging Force | 36KN |
Rotary Angle of excavator | 280° |
Loading parameters | |
Maximum unloading height | 3600mm |
Maximum unloading distance | 900mm |
Bucket width | 20 00mm |
Loading capacity | 1.2M3 |
Maximum lift height for loading | 4750mm |
Maximum rising power | 100KN |
Shovel action time and | 6.8s |
Steering system type | Articulated full hydraulic steering |
Steering Angle | 38° |
Tire | 16/70-24 |
Front wheel air pressure | 300-350kPa |
Rear wheel air pressure | 300-350kPa |
Service brake | air top oil caliper disc brake |
Parking brake | Air brake |
Fuel tank/Hydraulic oil tank | 70L/140L |
Driving Type | 4WD |
EXW | 24,000.00USD |
